| No. | Equipment name | Quantity | Total Rated Power | Total Price (FOB Qingdao) |
||
| (1). | JYQQ-1200 Tire Sidewall Cutter | 1 | Set | 5.5 | Kw | Please Contact us to inquire |
| (2). | JYQT-38 Tire Strip Cutter | 1 | Set | 5.5 | Kw | Please Contact us to inquire |
| (3). | JYQK-45 Tire Block Cutter | 1 | Set | 11 | Kw | Please Contact us to inquire |
| (4). | JYNQ-1200 Tire Bead Separator | 1 | Set | 15 | Kw | Please Contact us to inquire |
| (5). | JYXKP-280 Tire Block Crushing Line(Each Set Include One Jyxkp-280 Rubber Crusher,One Big Vibration Screen,One Returning Belt Conveyor, One Big Steel Wire Separator, One Small Vibration Screen And Three 2-Step Small Steel Wire Separator) | 1 | Set | 33.45 | Kw | Please Contact us to inquire |
| (6). | JYXF-500 FIBER SEPARATOR(EACH SET INCLUDE ONE SCREW LIFTER AND ONE TAPER-SHAPED SEPARATOR ) | 1 | Set | 10 | Kw | Please Contact us to inquire |
| Total: | 6 | Set | 80.45 | Kw | Please Contact us to inquire | |
| Working Area:200m2 Worker:2 person Average Power Consumption:40-50KW/hour. | ||||||
Remarks:
1). The capacity 200-300kgs/hour is based on 5-20mesh(0.85-4mm) output, if adjusted to 20-40mesh(0.35-0.85mm) output, the capacity will be 100-150Kgs/hour.
2). The total rated power is 80.45 Kw, but the Average Power Consumption is 40-50kw/hour only, because some machines don’t always work.
3). If you only want to recycle Steel Radial Tires, due to there are almost no fiber in Steel Radial Tires, you can cancel JYXF-500 Fiber Separator.Regarding the 200-300kgs/hour tire recycling plant with out JYXF-500 Fiber Separator, please visit https://www.usedtirerecycling.com/200-300kgs-per-hour-tyre-recycling-plant/
4). Above line can make 5-40mesh(0.85-4mm) rubber powder and also can screen out some 40-120mesh(0.12-0.85mm) superfine rubber powder, if you want to want to get much more 40-120mesh(0.12-0.85mm) superfine rubber powder in future, you can add one JYZM Superfine Rubber Powder Grinding Line.
5). If you want to weigh and pack recycled rubber crumb into bags automatically, you can add one JYDL-25-50 Automatic Weighing and Packing Machine.
6). We only published some simplest tyre recycling plants on our website,if you have special requirement or require other type of tyre recycling plant, please let us know your requirement, so that we can send you right plant to your Email, Ok?
