Rubber Floor Molding Molds For 450x450mm,550x550mm And 660x660mm Vulcanizing Machine

All Rubber Floor Molding Molds on this page can be installed on 450x450mm or 550x550mm, or 660x660mm Vulcanizing Press(Rubber Floor Tile Making Machine) to make high quality Rubber Floor Tiles.

The input material is Recycled Rubber Crumb, PU binder and Iron Oxide pigment after mixed by Rubber Crumb Mixers.

The output is High Quality Rubber Floor Tiles, the finished tile shape and size is the same as its mold.

Square Rubber Floor Molding Mould

 Faux Brick Rubber Floor Molding Molds

 Faux Stone rubber Floor Moulding Mould

 Hexagon Rubber Floor Molding Molds

Minimum Ordered Quantity: 1 male mold and 1 female mold of any mold you like.Remarks:

For ensure maximum production speed by one 4-layer vulcanizing machine, we suggest you buy at least 4 male molds and 8 female molds, so that 4 working layers can make Rubber Floor Tile at the same time and 8 female molds work in turn, that is when 4 male molds and 4 female molds is making Rubber Floor Tiles, the other 4 female molds can discharge finished tile and refill new material to prepare, avoid the finished tile discharging and new material refilling take curing time.

You can decide whether to make drainage channel(water way) on Rubber Floor Tile back.

Following photo showing the sketch of how to make waterway at the Rubber Floor Tile back, the drainage slotware will be delivered to you together with the Rubber Floor Tiles molds.

How to Make Rubber Tiles Waterway by Rubber Floor Molding Molds

Following photo showing the waterway slotwares we will put in one female mold and send to you free of charge.

Rubber Floor Molding Molds Waterway Slotwares Packing

From above photo, you can see that each female mold has two layers, so that you can remove one layer to adjust the finished tile greatly (from example from 40mm to 20mm), for ensuring you can change the finished tile thickness small (for example from 20mm to 25mm, from 25mm to 30mm,etc), we will send you enough Rubber Floor Molding Mold spacers as following photo showing.

Rubber Floor Molding Mould Spacers

You can decide whether to coat Teflon or not,following photo showing a rubber floor molding mold coated with Teflon coating, which can avoid the finished rubber floor tile adhere to the mold.

Rubber Floor Molding Mould With Teflon Coating

Above prices did not include the Teflon coating cost. Following photo showing a Rubber Floor Molding Mold coated with Teflon coatings, which can avoid the finished adhere to the Rubber Floor Molding Mold. You can decide whether to coat the mold with Teflon coating or not, if you want to know Teflon coating cost, please feel free to contact us.

Do you want to watch the video of making rubber floor tiles by vulcanizing machine and rubber floor molding molds? If so, please click below video and watch online.
