Application
Used to strip rubber from Car Tire Tread Belt, it also can be used to strip rubber from other rubber strips belts.
Structure
Mainly consists of frame, motor, gear reducer, shafts, coupling, pinching rolls, and stripping knife, etc.
Principle
The motor via reducer drive two pinching roll making relative motion to catch car tire tread belt or other rubber belts moving forward, the stripping blades will strip top rubber layer off.
Specification and Prices
| Model | JYBJ-700 |
| Power: | 3kw |
| Dimension: | 1.3x1x1.4m |
| Weight: | 600kg |
| Input: | Car tire tread belts or other rubber belt. |
| Output: | Rubber layer |
| Capacity: | 60-180 car tire treads belts per hour. |
| Disc Knife Dimension: | 700x60mm |
| Knife Quantity: | 1pcs |
| Blade Material: | SK5 Steel |
| Blade Hardness: | 55 HRC |
| Knife Rotation Speed: | 18rpm |
| Delivery Lead Time: | 10days(Exclude Legal Holiday). |
| Price: | Please contact us to inquire |
Working Video
Attention Please: When making this video,
works well in China, but now it does not work in China, so that you can not contact us by , if you want co contact us, please click here to contact us by other ways.
Hamed Motaleb
Dear sir
I am interested in your rubber striper machine.does the machine separate the steel belt and fiber belt from the tread?and how much does it cost to be exported to iran cif?
Regards
admin
Hello,Hamed Motaleb, our rubber stripper machine do not separate the steel belt and fiber belt from the tread, it only can strip the surface rubber from the tire tread. Best regards, Admin
paul
Can rubber stripper separate wire and rubber. From car tire. Because in South Africa car used tyre with wire
admin
Hello,Paul, JYBJ-700 Rubber Stripper is designed to strip pure rubber layer from the tire tread, it can not strip steel wire. Best regards, Admin
John White
Price?
admin
Dear Mr.John White. Thank you for inquiry about our JYBJ-700 Rubber Stripper, regarding the price and details, we have sent to your Email, now you can find the file in the inbox or spam box of your Email, please. Best regards, Web Admin
Gerald Grimm
What is the price of a JYBJ-700 shipped to muscoda WISC 53573 USA
admin
hello, Gerald, thank you for comment, we just sent the quotation to your Email, now you can find the quotation in the inbox or spam box of your email, please. Best regards, web Admin
