Application
The machine used to cut big rubber product(include bicycle tires and motorcycle tires) into small rubber scraps, so that can be fed into rubber granulators or rubber crushers to make rubber granules or rubber powder.
Structure
Mainly consists of frame, motor, reducer, shafts, fixed knife, moving knife, etc.
Principle
The motor via reducer drive the moving knife up and down, to make shear actions with fixed knife, so that to cut rubber products into rubber scraps.
Specification and Prices
| Model | JYDZ-580 |
| Power: | 3kw |
| Dimension: | 1.4×0.7×1.3m |
| Weight: | 300kg |
| Input: | Big Rubber Products. |
| Output: | Small Rubber Scraps. |
| Capacity: | 300-500kgs/hour |
| Knife Quantity: | 1 fixed knife and 1 moving knife. |
| Moving Knife Length: | 740mm |
| Fixed Knife Length: | 600mm |
| Knife Material: | Rapidsteel |
| Knife Hardness: | 60HRC |
| Knife Cutting Frequency: | 43times/minutes |
| Delivery Lead Time: | 10days(Exclude Legal Holiday). |
| Price: | Please contact us to inquire |
For machines on promotion, please visit below page.
